Tag: Security Panels

Portland Manilla 60 pre-crimped Architectural Mesh

Portland Manilla 60 Pre-Crimped Architectural Wire Mesh

A medium density, flat wire, intermediate crimp woven mesh, typically supplied in Stainless Steel and used for balustrades, facades, decorative radiator grilles, security panels and elevator cladding.

Hebrides Traditional Pre-crimped Wire Mesh

Specifications

MATERIAL	STAINLESS STEEL 316L
APERTURE	60 mm	WIRE	5 x 1.2 mm flat wire
OPEN AREA	55%	WEIGHT	3.6 kg/m²

Portland Manilla 60 Pre-Crimped Wire Mesh: printable specification sheet with 1:2 scale image.

Submit Enquiry.

Material Availability

Made to order in Mild or Stainless Steel, Aluminium, Phosphor Bronze, Copper and Brass.

Finishes

Powder coated finish available, provided the mesh is secured in a frame.

Fabrication

Locker Architectural can supply this mesh secured in a frame of your choosing.

Portland Manilla 60 architectural wire mesh is a Progress Architecture product, supplied and distributed in the UK and Ireland by Locker Architectural.

Open post

Churchill 25/25 Traditional Pre-crimped Wire Mesh

A medium density, crimped woven mesh, typically supplied in Stainless Steel and used for balustrades, facades, brie soleil, security panels and drapes.

Specifications

MATERIAL	Stainless Steel
APERTURE	25 x 25 mm	WIRE	2.5 mm
OPEN AREA	83%	WEIGHT	2.9 kg/m²

Churchill 25/25 Pre-Crimped Wire Mesh: printable specification sheet with 1:1 scale image.

Submit Enquiry.

A range of materials, aperture sizes and wire diameters are available.

Material Availability

Generally available in grades 316 and 304 stainless. Can also be made to
order in Galvanised Steel, Aluminium, Brass and Phosphor Bronze.

Finishes

Powder coated finish available, provided the mesh is secured in a frame.

Fabrication

Locker Architectural can supply this mesh secured in a frame of your choosing.

Open post

Churchill 46/46 Traditional Pre-crimped Wire Mesh

A medium density, crimped woven mesh, typically supplied in Brass and used for balustrades, facades, brie soleil, security panels and drapes.

Specifications

MATERIAL	BRASS
APERTURE	46 x 46 mm	WIRE	5 mm
OPEN AREA	81.4%	WEIGHT	7.54 kg/m²

Churchill 46/46 Pre-Crimped Wire Mesh: printable specification sheet with 1:1 scale image.

Submit Enquiry.

A range of materials, aperture sizes and wire diameters are available.

Material Availability

Generally available in Brass. Can also be made to order in 304 and 316 Stainless Steel, Galvanised Steel, Aluminium and Phosphor Bronze.

Finishes

Powder coated finish available, provided the mesh is secured in a frame.

Fabrication

Locker Architectural can supply this mesh secured in a frame of your choosing.

Open post

Churchill 11/11 Copper

Churchill 11/11 Copper Wire Mesh

A medium-density, intermediate-crimp woven mesh.

Typically supplied in copper or brass, and used for bar grilles, room dividers, and other ornamental metalwork.

Download PDF Technical Sheet

Material Availability

Readily available in both Copper and Brass. Made to order in other materials such as stainless steel, mild steel, etc.

Finishes

Powder coated finish available, provided the mesh is secured in a frame.

Fabrication

Locker Architectural can supply this mesh secured in a frame of your choosing.

Enquire about this mesh

Please do not hesitate to get in touch to discuss your project, our early involvement often saves substantial time later on.

Open post

Forth-5050-architectural-welded-wire-mesh

Forth 5050 Welded Wire Mesh

Specification

Reference	Nominal Opening mm	Nominal Wire Diameter mm	Open Area %	Weight kg/m²
5050/3	47 x 47	3	88	2.4
5050/2.5	47.5 x 47.5	2.5	90	1.7

Forth 5050 Welded Wire Mesh: printable specification sheet with 1:1 scale image

Availability

Stainless Steel 316 and 304, Plain and Galvanised Steel.

Typical Applications

Balustrades, façades and security panels.

Locker is a UK based supplier of architectural wire mesh products certified to BS EN ISO 9001:2015.

With comprehensive in-house 3D design facilities we are able to offer a complete package from development of the architectural wire mesh specification through design, fabrication, supply and installation of the finished screens.
