gladstone_80_10 woven wire mesh

Gladstone PC 80/10 Pre-Crimped Wire Mesh

Gladstone PC 80/10 Pre-crimped Wire Mesh


Gladstone PC 80/10 Pre-crimped Wire Mesh

Specifications

MATERIALSTAINLESS STEEL 316L
RODS3 mmAPERTURE7.4 mm
WIRES3 x 2.5 mmAPERTURE67.5 mm
OPEN AREA64%WEIGHT7.4 kg/m²

Gladstone PC 80/10 Pre-Crimped Wire Mesh: printable specification sheet with 1:1 scale image.

Availability

Generally available in grades 316 and 304 stainless. Can also be made to order in Galvanised Steel, Aluminium, Brass and Phosphor Bronze.

Typical Applications

Balustrades, façades, brise soleil, security panels and car park cladding.

Locker is a UK based supplier of architectural wire mesh products certified to BS EN ISO 9001:2015 and Achilles 'Building Confidence' Level 4.

With comprehensive in house 3D design facilities we are able to offer a complete package from development of the architectural wire mesh specification through design, fabrication, supply and installation of the finished screens.

Open post
gladstone-pc-74-3-75 precrimped woven wire mesh

Gladstone PC 74/3-75 Pre-Crimped Wire Mesh

Gladstone PC 74/3-75 Pre-crimped Wire Mesh


Gladstone PC 74/3-75 Pre-crimped Wire Mesh

Specifications

MATERIALSTAINLESS STEEL 316L
RODS2.5 mmAPERTURE74 mm
WIRES3 x 2 mmAPERTURE3.75 mm
OPEN AREA55%WEIGHT7.8 kg/m²

Gladstone PC 74/3-75 Pre-Crimped Wire Mesh: printable specification sheet with 1:1 scale image.

Availability

Generally available in grades 316 and 304 stainless. Can also be made to order in Galvanised Steel, Aluminium, Brass and Phosphor Bronze.

Typical Applications

Balustrades, façades, brise soleil and security panels.

Locker is a UK based supplier of architectural wire mesh products certified to BS EN ISO 9001:2015 and Achilles 'Building Confidence' Level 4.

With comprehensive in house 3D design facilities we are able to offer a complete package from development of the architectural wire mesh specification through design, fabrication, supply and installation of the finished screens.

Open post
gladstone pc 423 Precrimped wire mesh

Gladstone PC 42/3 Pre-Crimped Wire Mesh

Gladstone PC 42/3 Pre-crimped Wire Mesh


Gladstone PC 42/3 Pre-crimped Wire Mesh

Specifications

MATERIALSTAINLESS STEEL 316L
RODS3 mmAPERTURE3 mm
WIRES4 x 2 mmAPERTURE42 mm
OPEN AREA42%WEIGHT11.97 kg/m²

Gladstone PC 42/3 Pre-Crimped Wire Mesh: printable specification sheet with 1:1 scale image.

Availability

Generally available in grades 316 and 304 stainless. Can also be made to order in Galvanised Steel, Aluminium, Brass and Phosphor Bronze.

Typical Applications

Balustrades, façades, brise soleil, security panels and drapes.

Locker is a UK based supplier of architectural wire mesh products certified to BS EN ISO 9001:2015 and Achilles 'Building Confidence' Level 4.

With comprehensive in house 3D design facilities we are able to offer a complete package from development of the architectural wire mesh specification through design, fabrication, supply and installation of the finished screens.

Open post
gladstone_pc_312 woven wire mesh

Gladstone PC 31/2 Pre-Crimped Wire Mesh

Gladstone PC 31/2 Pre-crimped Wire Mesh


Gladstone PC 31/2 Pre-crimped Wire Mesh

Specifications

MATERIALSTAINLESS STEEL 316L
RODS2 mmAPERTURE31 mm
WIRES3 x 1.25 mmAPERTURE2 mm
OPEN AREA43.1%WEIGHT7.38 kg/m²

Gladstone PC 31/2 Pre-Crimped Wire Mesh: printable specification sheet with 1:1 scale image.

Availability

Generally available in grades 316 and 304 stainless. Can also be made to order in Galvanised Steel, Aluminium, Brass and Phosphor Bronze.

Typical Applications

Balustrades, façades, brise soleil and drapes.

Locker is a UK based supplier of architectural wire mesh products certified to BS EN ISO 9001:2015 and Achilles 'Building Confidence' Level 4.

With comprehensive in house 3D design facilities we are able to offer a complete package from development of the architectural wire mesh specification through design, fabrication, supply and installation of the finished screens.

Open post
gladstone-pc-232-precrimped woven wire-mesh

Gladstone PC 23/2 Pre-Crimped Wire Mesh

Gladstone PC 23/2 Pre-crimped Wire Mesh


Gladstone PC 23/2 Pre-crimped Wire Mesh

Specifications

MATERIALSTAINLESS STEEL 316L
RODS1.6 mmAPERTURE2 mm
WIRES3 x 1 mmAPERTURE23 mm
OPEN AREA53%WEIGHT5.8 kg/m²

Gladstone PC 23/2 Pre-Crimped Wire Mesh: printable specification sheet with 1:1 scale image.

Availability

Typically available in Stainless Steel 304L and 316L. Other materials available on request.

Typical Applications

Suspended ceilings, interior and furniture cladding, façades, drapes, feature walls.

Locker is a UK based supplier of architectural wire mesh products certified to BS EN ISO 9001:2015 and Achilles 'Building Confidence' Level 4.

With comprehensive in house 3D design facilities we are able to offer a complete package from development of the architectural wire mesh specification through design, fabrication, supply and installation of the finished screens.

Open post
gladstone_pc_2316 precrimped woven wire mesh

Gladstone PC 23/1-6 Pre-Crimped Wire Mesh

Gladstone PC 23/1-6 Pre-crimped Wire Mesh


Gladstone PC 23/1-6 Pre-crimped Wire Mesh

Specifications

MATERIALSTAINLESS STEEL 316L
RODS1.6 mmAPERTURE1.6 mm
WIRES3 x 1 mmAPERTURE23.4 mm
OPEN AREA44%WEIGHT5.8 kg/m²

Gladstone PC 23/1-6 Pre-Crimped Wire Mesh: printable specification sheet with 1:1 scale image.

Availability

Generally available in grades 316 and 304 stainless. Can also be made to order in Galvanised Steel, Aluminium, Brass and Phosphor Bronze.

Typical Applications

Balustrades, façades, brise soleil, security panels and drapes.

Locker is a UK based supplier of architectural wire mesh products certified to BS EN ISO 9001:2015 and Achilles 'Building Confidence' Level 4.

With comprehensive in house 3D design facilities we are able to offer a complete package from development of the architectural wire mesh specification through design, fabrication, supply and installation of the finished screens.

Open post
gladstone_pc_100_10 precrimped woven wire mesh

Gladstone PC 100/10 Pre-Crimped Wire Mesh

Gladstone PC 100/10 Pre-crimped Wire Mesh


Gladstone PC 100/10 Pre-crimped Wire Mesh

Specifications

MATERIALSTAINLESS STEEL 316L
RODS4 mmAPERTURE10 mm
WIRES3 x 3 mmAPERTURE91 mm
OPEN AREA65%WEIGHT9.32 kg/m²

Gladstone PC 100/10 Pre-Crimped Wire Mesh: printable specification sheet with 1:1 scale image.

Availability

Generally available in grades 316 and 304 stainless. Can also be made to order in Galvanised Steel, Aluminium, Brass and Phosphor Bronze.

Typical Applications

Balustrades, façades, brise soleil, security panels and car park cladding.

Locker is a UK based supplier of architectural wire mesh products certified to BS EN ISO 9001:2015 and Achilles 'Building Confidence' Level 4.

With comprehensive in house 3D design facilities we are able to offer a complete package from development of the architectural wire mesh specification through design, fabrication, supply and installation of the finished screens.

Open post
brocklebank-165-precrimped-wire-mesh

Brocklebank 16/5 Pre-Crimped Wire Mesh

Brocklebank 16/5 Pre-crimped Wire Mesh


Brocklebank 16/5 Pre-crimped Wire Mesh

Specifications

MATERIALALUMINIUM
CRIMPED WIRE2 mmAPERTURE15.5 mm
FLAT TOP WIRE2 mmAPERTURE5 mm
OPEN AREA63%WEIGHT 1.84 kg/m²

Brocklebank 16/5 Pre-Crimped Wire Mesh: printable specification sheet with 1:1 scale image.

Availability

Generally available in grades 316 and 304 stainless. Can also be made to order in Galvanised Steel, Aluminium, Brass and Phosphor Bronze.

Typical Applications

Ceilings, balustrades, façades, brise soleil and security panels.

Locker is a UK based supplier of architectural wire mesh products certified to BS EN ISO 9001:2015 and Achilles 'Building Confidence' Level 4.

With comprehensive in house 3D design facilities we are able to offer a complete package from development of the architectural wire mesh specification through design, fabrication, supply and installation of the finished screens.

Open post
brocklebank_152 precrimped woven wire mesh

Brocklebank 15/2 Pre-Crimped Wire Mesh

Brocklebank 15/2 Pre-crimped Wire Mesh


Brocklebank 15/2 Pre-crimped Wire Mesh

Specifications

MATERIALSTAINLESS STEEL
APERTURE15.5 x 2 mmWIRE1 x 2 x 1.5 mm
OPEN AREA49%WEIGHT 6.26 kg/m²

Brocklebank 15/2 Pre-Crimped Wire Mesh: printable specification sheet with 1:1 scale image.

Availability

Generally available in grades 316 and 304 stainless. Can also be made to order in Galvanised Steel, Aluminium, Brass and Phosphor Bronze.

Typical Applications

Balustrades, façades, brise soleil, security panels and drapes.

Locker is a UK based supplier of architectural wire mesh products certified to BS EN ISO 9001:2015 and Achilles 'Building Confidence' Level 4.

With comprehensive in house 3D design facilities we are able to offer a complete package from development of the architectural wire mesh specification through design, fabrication, supply and installation of the finished screens.

Open post
brocklebank_203 precrimped woven wire mesh

Brocklebank 20/3 Pre-Crimped Wire Mesh

Brocklebank 20/3 Pre-crimped Wire Mesh


Brocklebank 20/3 Pre-crimped Wire Mesh

Specifications

MATERIALSTAINLESS STEEL
APERTURE20 x 3 mmWIRE2.5 x 3 mm
OPEN AREA47%WEIGHT 9.82 kg/m²

Brocklebank 20/3 Pre-Crimped Wire Mesh: printable specification sheet with 1:1 scale image.

Availability

Generally available in grades 316 and 304 stainless. Can also be made to order in Galvanised Steel, Aluminium, Brass and Phosphor Bronze.

Typical Applications

Balustrades, façades, brise soleil, security panels and external stair towers.

Locker is a UK based supplier of architectural wire mesh products certified to BS EN ISO 9001:2015 and Achilles 'Building Confidence' Level 4.

With comprehensive in house 3D design facilities we are able to offer a complete package from development of the architectural wire mesh specification through design, fabrication, supply and installation of the finished screens.
